Spherical Lifting Air Cushion
The ball-shaped chamber hugs curved and irregular loads, delivering stable lifting force from a single contact point — the answer to traffic accidents, house collapses, railway rescue and overturning heavy objects.
32 to 180 Tons of Lifting Force in Seconds
Used in traffic accidents, house collapses and other rescue scenes, the spherical cushion lifts 32 to 180 tons with fast lifting speed. A single cushion lifts 30–70 cm and multiple cushions can be superimposed for extra height.
- High safety performance — aromatic polyamide with high-strength Kevlar cord
- Anti-static, crack-resistant — wear, oil and ageing resistant
- 1.3 MPa working pressure — 3 cm body, 7.5 cm insertion height
- Stackable — multiple cushions superimposed for large-stroke lifting
- Fast — rapid lift suitable for time-critical rescue
Spherical Lifting Airbag Specification (1.3 MPa, Kevlar)
| Model | Material | Working Pressure (MPa) | Diameter (mm) | Thickness (cm) | Max Lifting (t) | Max Lifting Height (cm) | Weight (kg) | Structure Height (cm) |
|---|---|---|---|---|---|---|---|---|
| HY-QQD32/1.3 | Kevlar | 1.3 | ⌀560 | 3 | 32 | 30 | 13 | 7.5 |
| HY-QQD75.5/1.3 | Kevlar | 1.3 | ⌀880 | 3 | 75.5 | 45 | 26 | 7.5 |
| HY-QQD110/1.3 | Kevlar | 1.3 | ⌀1090 | 3 | 110 | 52 | 39 | 7.5 |
| HY-QQD181.1/1.3 | Kevlar | 1.3 | ⌀1350 | 3 | 181.1 | 70 | 55 | 7.5 |
Lifting pressure ranges from 30 tons to 180 tons. Exact parameters are confirmed per order and factory test report. Custom sizes available (OEM/ODM welcome).
Where Spherical Cushions Are Used
Railway & Heavy Vehicle Rescue
Upright and reset derailed, overturned rail carriages and locomotives; jack up heavy tank wagons for re-railing, position correction and on-site emergency repair. Multi-layer stacked spherical airbags achieve large-stroke lifting for heavy railway vehicles.
Traffic Accidents & House Collapses
When a slab, vehicle or machine pins a victim, the spherical cushion raises the load with controlled pneumatic force. Lifting pressure ranges from 30 to 180 tons with fast lifting speed and a single-cushion lift height of 30–70 cm.
Watch It in Action
See our lifting air cushions and equipment operated in real situations.
►
Spherical Air Cushion Operation
Full lifting demonstration with spherical air cushions. Operation and inflation videos are in the video center.
